A 600 kVA UPS (Uninterruptible Power Supply) is a high-capacity three-phase online double-conversion UPS used to provide uninterrupted, clean power for mission-critical applications such as data centers, hospitals, airports, manufacturing plants, and large commercial facilities. Modern systems typically provide up to 600 kW of output power (power factor 1.0), although some models are rated lower depending on the design.
Typical 600 kVA UPS Specifications
| Parameter | Specification |
|---|---|
| Capacity | 600 kVA |
| Output Power | Up to 600 kW (model dependent) |
| Technology | Online Double Conversion |
| Input Voltage | 380/400/415 VAC, 3 Phase + Neutral |
| Output Voltage | 380/400/415 VAC |
| Frequency | 50/60 Hz |
| Input Power Factor | >0.99 |
| Input THDi | <3–5% |
| Transfer Time | 0 ms |
| Output Voltage Regulation | ±1% |
| Battery Type | External VRLA or Lithium-ion battery bank |
| Communication | LCD display, SNMP, Modbus, RS-232/USB (model dependent) |
| Efficiency | Up to 99% in ECO mode (varies by manufacturer) |
Key Features
- Online double-conversion technology for continuous clean power
- Zero transfer time during mains failure
- High efficiency and low input harmonic distortion
- Intelligent battery management for longer battery life
- Generator compatible
- Parallel redundancy and capacity expansion options
- Remote monitoring through SNMP/Modbus
- Advanced protection against overloads, short circuits, and voltage fluctuations
Typical Applications
- Large data centers
- Industrial manufacturing plants
- Hospitals and healthcare facilities
- Airports and metro systems
- Banking and financial institutions
- Oil & gas facilities
- Telecom infrastructure
