The Vertiv™ Liebert® MTP 120 kVA UPS is a three-phase online double-conversion UPS designed for critical power applications such as data centers, industrial plants, hospitals, commercial buildings, and manufacturing facilities.
Vertiv 120 kVA UPS – Key Specifications
| Parameter | Specification |
|---|---|
| Capacity | 120 kVA / 120 kW |
| Technology | Online Double Conversion |
| Input Voltage | 380/400/415 VAC, 3 Phase + Neutral |
| Output Voltage | 380/400/415 VAC |
| Frequency | 50/60 Hz |
| Input Power Factor | Up to 0.99 |
| Input THDi | <4% at full load |
| Transfer Time | 0 ms |
| Battery Type | External VRLA or Lithium-ion battery bank |
| Battery Configuration | 192–240 lead-acid cells (nominal 216 cells) |
| Efficiency | High efficiency with ECO mode available (model dependent) |
| Communication | LCD display, RS-232, USB, SNMP/Modbus options |
| Dimensions (D × W × H) | 1000 × 430 × 1200 mm |
| Approximate Weight | 169 kg (without batteries) |
Typical Applications
- Industrial automation
- Data centers and server rooms
- Hospitals and diagnostic equipment
- Commercial buildings
- Manufacturing plants
- Telecom infrastructure
Key Features
- Zero transfer time during power failure
- DSP-controlled online double-conversion technology
- Generator compatible
- Intelligent battery management
- Wide input voltage range
- High overload capability
- Remote monitoring through optional SNMP/Modbus communication
- Easy maintenance and service access
